Specification MCAC-TSM-2008-02
58 Installation
7. Error code Er62:
Values display indication Er62
Refer to the instruction manual: Coil sensor T03 malfunction.
Judge 1: Whether the sensor falls off. Insert it well.
Yes
No
Judge 2: Check the electrical connection,
whether the sensor connects well.
No
Connect it well.
Yes
Jud
e 3: Whether coil sensor T03 is malfunction
Yes
Replace coil sensor
T03
No
Judge 4: PCB is malfunction
Replace PCB
Yes
To Next Page
