M thermal Split
108 202004
Midea M thermal Split
5.1 Temperature Sensor Resistance Characteristics
Table 4-5.1: Outdoor ambient temperature sensor, water side heat exchanger refrigerant inlet / outlet (liquid / gas pipe) temperature sensor
air side heat exchanger refrigerant out temperature sensor and suction pipe temperature sensor resistance characteristics
Temperature
(°C)
Resistance
(k )
Temperature
(°C)
Resistance
(k )
Temperature
(°C)
Resistance
(k )
Temperature
(°C)
Resistance
(k )
-25 144.266 15 16.079 55 2.841 95 0.708
-24 135.601 16 15.313 56 2.734 96 0.686
-23 127.507 17 14.588 57 2.632 97 0.666
-22 119.941 18 13.902 58 2.534 98 0.646
-21 112.867 19 13.251 59 2.44 99 0.627
-20 106.732 20 12.635 60 2.35 100 0.609
-19 100.552 21 12.05 61 2.264 101 0.591
-18 94.769 22 11.496 62 2.181 102 0.574
-17 89.353 23 10.971 63 2.102 103 0.558
-16 84.278 24 10.473 64 2.026 104 0.542
-15 79.521 25 10 65 1.953 105 0.527
-14 75.059 26 9.551 66 1.883
-13 70.873 27 9.125 67 1.816
-12 66.943 28 8.721 68 1.752
-11 63.252 29 8.337 69 1.69
-10 59.784 30 7.972 70 1.631
-9 56.524 31 7.625 71 1.574
-8 53.458 32 7.296 72 1.519
-7 50.575 33 6.982 73 1.466
-6 47.862 34 6.684 74 1.416
-5 45.308 35 6.401 75 1.367
-4 42.903 36 6.131 76 1.321
-3 40.638 37 5.874 77 1.276
-2 38.504 38 5.63 78 1.233
-1 36.492 39 5.397 79 1.191
0 34.596 40 5.175 80 1.151
1 32.807 41 4.964 81 1.113
2 31.12 42 4.763 82 1.076
3 29.528 43 4.571 83 1.041
4 28.026 44 4.387 84 1.007
5 26.608 45 4.213 85 0.974
6 25.268 46 4.046 86 0.942
7 24.003 47 3.887 87 0.912
8 22.808 48 3.735 88 0.883
9 21.678 49 3.59 89 0.855
10 20.61 50 3.451 90 0.828
11 19.601 51 3.318 91 0.802
12 18.646 52 3.191 92 0.777
13 17.743 53 3.069 93 0.753
14 16.888 54 2.952 94 0.73
Table 4-5.2:
Compressor discharge pipe temperature sensor resistance characteristics
