M thermal Split
202004 33
Main PCB
Inverter module
Figure 4-1.4: MHA-V12(14,16)W/D2RN8-B electric control box
Main PCB
Inverter module
Main Power
Electric Reactor
Filter board
DCFAN Electric
Reactor
