4-way cassette FCU MCAC-KTSM-2012-02
22 Exploded View
No. Part Name Qty No. Part Name Qty
1 Electric control box head cover I 1 16 Wire clip 1
2 Electric control box head cover II 1 17 Drip tray assembly 1
3 Electric control box assembly of indoor unit 1 18 Evaporator fixing hook 3
3.1 Electric control box welded assembly 1 19 Water pump baffle plate 1
3.2 Transformer 1 20 Water drain pump subassembly 1
3.3 Capacitor 1 21 Water pump installation bracket subassembly 1
3.4 Four sides air outlet indoor main control plate 1 22 Front barrier IV subassembly 1
3.5 7-hole wiring terminal 1 23 Water pump pumping pipe grommet 1
4 Air inducting coils subassembly 1 24 Fan fixer 1
5 Foam subassembly, drain tray 1 25 Water finder cover subassembly 1
6 Fan assembly 1 26 Front barrier III subassembly 1
7 Evaporator fixing board 1 26.1 Install lifting lug 4
8 Evaporator assembly 1 27 Water pumping connect pipe 1
8.1 Evaporator 1 28 Exhalant tube seal plate subassembly 1
8.2 Evaporator output tube assembly 1 29 Water pump's rubber pad 1
8.3 Evaporator filter assembly 1 30 Remote controller 1
8.4 Barrel 1 31 Fan protecting net 1
8.5 Discharge assembly 1 32 Bracket, remote controller 1
9 Front barrier I subassembly 1 33 Front panel 1
10 Foam seat subassembly 1 33.1 Panel assembly 1
11 Front barrier II subassembly 1 33.2 Swing motor 2
12 Asynchronous dynamo 1 33.3 Room temperature sensor 1
13 Base pan welded assembly 1 34 Evaporator temperature sensor 1
14 Plate, wire 1 35 Drain water level sensor 1
15 Tandem, wire 1
