4-way cassette FCU MCAC-KTSM-2012-02
24 Exploded View
No Part Name Qty No Part Name Qty
1 Electric control box head cover I 1 16 Tandem, wire 1
2 Electric control box head cover II 1 17 Wire clip 1
3 Electric control box assembly of indoor unit 1 18 Drip tray assembly 1
3.1 Electric control box welded assembly 1 19 Evaporator fixing hook 3
3.2 Voltage transformer 1 20 Water pump baffle plate 1
3.3 Supporter of electrical heater 1 21 Water drain pump subassembly 1
3.4 Capacitor 1 22
Water pump installation bracket
subassembly
1
3.5 Four sides air outlet indoor main control plate 1 23 Front barrier IV subassembly 1
3.6 7-hole wring terminal 1 24 Water pump pumping pipe grommet 1
4 Air inducting coils subassembly 1 25 Fan fixer 1
5 Foam subassembly, drain tray 1 26 Water finder cover subassembly 1
6 Fan assembly 1 27 Front barrier III subassembly 1
7 Evaporator fixing board 1 27.1 Install lifting lug 4
8 Evaporator assembly 1 28 Water pumping connect pipe 1
8.1 Evaporator 1 29 Exhalant tube seal plate subassembly 1
8.2 Evaporator output tube assembly 1 30 Water pump's rubber pad 1
8.3 Evaporator input tube assembly 1 31 Remote controller 1
8.4 Discharge assembly 1 32 Fan protecting net 1
8.5 Barrel 1 33 Bracket, remote controller 1
9 Front barrier I subassembly 1 34 Front panel 1
10 Foam seat subassembly 1 34.1 Swing motor 2
11 Front barrier II subassembly 1 34.2 Panel 1
12 Asynchronous dynamo 1 35 Evaporator temperature sensor 1
13 Base pan seat 1 36 Drain water level sensor 1
14 Base pan welded assembly 1 37 Auxiliary electrical heater assembly 1
15 Plate, wire 1
