4-way cassette FCU MCAC-KTSM-2012-02
8 Specifications
Specifications
Model MKA-
950R(A) 1200R(A) 1500R
Air Volume
High
m
3
/h 1600 2000 2550
CFM 940 1180 1500
Med
m
3
/h 1360 1700 2170
CFM 800 1000 1280
Low
m
3
/h 1150 1440 1840
CFM 680 850 1080
Cooling Capacity (Hi/Med/Lo) W 8.22/7.39/6.54 10.39/9.25/8.2 12.9/11.51/10.21
Heating Capacity (Hi/Med/Lo) W 13.85/11.08/9 17.58/14.06/11.42 17.6/14.08/11.44
Electrical Auxiliary Heater (EAH) W 2850 2850 /
Power Input W 155 190 190
Noise (Hi/Med/Lo) dB(A) 48/44/39 49/45/40 50/46/41
Water Flow l/min 23.6 29.8 36.9
Water Pressure Drop kPa 31.2 44 40
Fan Motor
Type Low noise 4-speed fan motor
Model YDK90-6E YDK90-6E YDK90-6E-1
Brand Welling/Dayang Welling/Dayang Welling/Dayang
Capacitor 3.5
Quantity 1
Fan
Type Centrifugal, forward-curved Blades
Quantity 1
Coil
Diameter mm Φ7
Row 2 2 3
Tube pitch(a)xrow pitch(b) mm 21×13.37
Fin spacing mm 1.5
Fin type Hydrophilic aluminium
Coil length x height x width mm 1960×252×26.74 1960×252×26.74 2080x252x40.11
Max. Working Pressure MPa 1.6
Circuit 12 12 12
Panel
Net Dimension (W×H×D) mm 950×45×950
Net Weight kg 6
Packing Size (W×H×D) mm 1035×90×1035
Gross Weight kg 9
Indoor Unit
Net Dimension (W×H×D) mm 840×300×840
Net Weight (without/with EAH) kg 30.5/33 30.5/33 35
Packing Size (W×H×D) mm 900×307×900
Gross Weight (without/with EAH) kg 36.2/39 36.2/39 41
Pipe
Connection
Water-inlet pipe Inch RC3/4"
Water-outlet pipe Inch RC3/4"
Drain pipe mm ODΦ32
Note:1. The data is the performance in high speed with relevant static pressure.
2. Cooling Conditions: Entering Water 7°C, Temperature Rise 5°C, Entering Air Temperature 27°C DB,19°CWB.
Heating Conditions: Entering Water 50°C, enter air temperature 20°C, the same water flow as the cooling conditions.
3. Noise is tested in full-anechoic test room.
