Midea MKG Series - Heating Capacity MKG-500-B

AC Fan Coil Unit Two-pipe Wall-
mounted Series
- 64 -
Heating Capacity
MKG-500-B
EWT ΔT
Indoor temperature (W.B.)
16 18 20 22
TH WF WPD TH WF WPD TH WF WPD TH WF WPD
°C °C kW m
3
/h kPa kW m
3
/h kPa kW m
3
/h kPa kW m
3
/h kPa
40
8 4.57 0.49 11.80 4.03 0.43 9.56 3.48 0.37 7.53 2.94 0.32 5.69
10 4.60 0.40 6.95 3.98 0.34 5.48 3.36 0.29 4.14 2.74 0.24 2.96
12 - - - - - - - - - - - -
14 - - - - - - - - - - - -
16 - - - - - - - - - - - -
45
8 5.65 0.61 18.57 5.13 0.55 15.83 4.61 0.50 13.27 4.09 0.44 10.91
10 5.42 0.47 10.85 4.87 0.42 9.10 4.33 0.37 7.49 3.79 0.33 6.02
12 5.19 0.37 6.81 4.61 0.33 5.61 4.04 0.29 4.51 3.47 0.25 3.50
14 4.90 0.30 4.41 4.29 0.26 3.54 3.68 0.23 2.75 3.07 0.19 2.04
16 4.31 0.23 2.41 3.70 0.20 1.87 3.09 0.17 1.39 2.47 0.13 0.96
50
8 6.77 0.73 27.03 6.26 0.67 23.75 5.75 0.62 20.65 5.25 0.56 17.75
10 6.51 0.56 15.93 5.98 0.51 13.87 5.46 0.47 11.93 4.94 0.43 10.12
12 6.30 0.45 10.29 5.75 0.41 8.85 5.21 0.37 7.51 4.67 0.33 6.27
14 6.05 0.37 6.93 5.48 0.34 5.88 4.91 0.30 4.91 4.34 0.27 4.01
16 5.79 0.31 4.82 5.19 0.28 4.02 4.59 0.25 3.29 3.99 0.21 2.61
55
8 7.85 0.84 36.78 7.35 0.79 32.97 6.85 0.74 29.35 6.36 0.68 25.93
10 7.63 0.66 22.12 7.11 0.61 19.71 6.60 0.57 17.43 6.10 0.52 15.28
12 7.41 0.53 14.33 6.88 0.49 12.67 6.35 0.46 11.11 5.83 0.42 9.65
14 7.16 0.44 9.80 6.61 0.41 8.60 6.07 0.37 7.46 5.53 0.34 6.40
16 6.91 0.37 7.02 6.34 0.34 6.09 5.78 0.31 5.22 5.22 0.28 4.41
60
8 8.97 0.96 48.22 8.47 0.91 43.85 7.97 0.86 39.72 7.48 0.80 35.78
10 8.78 0.76 29.54 8.27 0.71 26.75 7.76 0.67 24.10 7.26 0.62 21.58
12 8.58 0.61 19.37 8.05 0.58 17.45 7.53 0.54 15.63 7.02 0.50 13.91
14 8.34 0.51 13.46 7.81 0.48 12.06 7.27 0.45 10.73 6.75 0.41 9.47
16 8.10 0.44 9.73 7.55 0.41 8.66 7.00 0.38 7.65 6.46 0.35 6.69
Abbreviations:
Δt: Temperature Difference. (℃)
TH: Total Heating Capacity. (kW) WF: Water Flow. (m
3
/h) WPD: Water Pressure Drop. (kPa)
