Product Features
Page 86
Putty
Putty
Putty
Trap
Trap
Trap
Note: DO NOT allow water to enter the remote control. Use the trap and putty to seal the wires.
• For exposed mounting, four outletting positions. There are three need cutting.
Cutting place of top
side wire outlet
Cutting place of left
side wire outlet
Cutting place of righ
t
side wire outlet
• For shielded wiring, please refer to the picture below.
Embedded switch
box wiring
Wiring
hole
Wiring through the wall
Wall hole and wiring hole
