Specifications
Page 43
INDOOR
AIRFLOW
(CMH)
OUTDOOR
DB(℃)
ID WB
(℃)
16.0 18.0 19.0 22.0
ID DB
(℃)
23.0 25.0 27.0 30.0 23.0 25.0 27.0 30.0 23.0 25.0 27.0 30.0 23.0 25.0 27.0 30.0
2160
27
TC 10.6 10.7 10.8 11.0 11.1 11.1 11.2 11.3 11.5 11.5 11.5 11.6 12.3 12.3 12.3 12.3
S/T 0.78 0.96 1.00 1.00 0.63 0.81 0.91 1.00 0.53 0.70 0.81 1.00 0.31 0.47 0.57 0.75
PI 3.34 3.34 3.34 3.34 3.34 3.34 3.34 3.34 3.34 3.34 3.34 3.34 3.35 3.35 3.35 3.35
30
TC 10.3 10.4 10.6 10.7 10.8 10.8 10.9 11.0 11.1 11.1 11.1 11.3 12.0 12.0 12.0 12.0
S/T 0.79 0.98 1.00 1.00 0.63 0.82 0.92 1.00 0.54 0.71 0.82 1.00 0.31 0.48 0.58 0.76
PI 3.52 3.52 3.52 3.52 3.53 3.53 3.53 3.53 3.53 3.53 3.53 3.53 3.55 3.55 3.55 3.55
32
TC 10.1 10.2 10.3 10.4 10.6 10.6 10.7 10.8 10.9 10.9 10.9 11.0 11.8 11.8 11.8 11.8
S/T 0.80 0.99 1.00 1.00 0.64 0.82 0.93 1.00 0.54 0.72 0.83 1.00 0.31 0.48 0.58 0.77
PI 3.65 3.65 3.65 3.65 3.66 3.66 3.66 3.66 3.67 3.67 3.67 3.67 3.69 3.69 3.69 3.69
35
TC 9.8 9.9 10.0 10.1 10.3 10.3 10.4 10.5 10.6 10.6 10.8 10.9 11.4 11.4 11.4 11.4
S/T 0.81 1.00 1.00 1.00 0.64 0.84 0.95 1.00 0.54 0.73 0.83 1.00 0.31 0.48 0.58 0.78
PI 3.86 3.86 3.86 3.86 3.87 3.87 3.87 3.87 3.87 3.87 3.88 3.87 3.90 3.90 3.90 3.90
43
TC 8.9 9.0 9.1 9.2 9.3 9.4 9.5 9.6 9.6 9.6 9.7 9.8 10.4 10.4 10.4 10.4
S/T 0.84 1.00 1.00 1.00 0.66 0.88 1.00 1.00 0.55 0.76 0.88 1.00 0.30 0.49 0.60 0.90
PI 4.49 4.49 4.49 4.49 4.51 4.51 4.51 4.51 4.52 4.52 4.52 4.52 4.55 4.55 4.55 4.55
46
TC 8.6 8.6 8.7 8.8 9.0 9.1 9.1 9.2 9.3 9.3 9.3 9.4 10.1 10.1 10.1 10.1
S/T 0.86 1.00 1.00 1.00 0.67 0.89 1.00 1.00 0.56 0.77 0.90 1.00 0.30 0.49 0.61 0.92
PI 4.73 4.73 4.73 4.73 4.75 4.75 4.75 4.75 4.76 4.76 4.76 4.76 4.80 4.80 4.80 4.80
52
TC 7.7 7.8 7.9 8.0 8.1 8.2 8.3 8.4 8.4 8.4 8.5 8.6 9.1 9.1 9.1 9.1
S/T 0.90 1.00 1.00 1.00 0.70 0.94 1.00 1.00 0.57 0.81 0.95 1.00 0.29 0.51 0.64 0.97
PI 5.34 5.34 5.34 5.34 5.36 5.36 5.36 5.36 5.37 5.37 5.37 5.37 5.41 5.41 5.41 5.41
TC:Total Cooling Capacity (kW)
S/T:Sensible Cooling Capacity Ratio
PI:Power Input(kW)
