12. Remove the old upper door self-locking block and the door self-closing (do
not remove the parts attached in step 10). Store in a safe place in case you
need to reverse the door position again.
13. Attach the refrigerator door to the bottom hinge, then attach the center hinge
to the refrigerator. Use the center hinge from the hinge kit (not the piece
removed in step 4).
14. Put the freezer door onto the center hinge, then attach the top hinge (from the
hinge kit) to the top of refrigerator. Cover the hinge with the top hinge cover
(from the hinge kit) and cover the screw holes on the top with the cover plate
you previously removed.
Attach the top hinge
Attach the center hinge
15. Add covers to the screw holes and hinge pivot.
