Midea MTA-120CRN1 Service Manual

Air-cooled Package DM13-01.01.16en
30 Service manual
Gross Cooling Capacity (kW)
Outdoor DB(°C) 40.60 46.10 51.70
Indoor WB(°C) 16.10 19.40 22.80 16.10 19.40 22.80 16.10 19.40
22.80
CFM DB(°C) TGC SHC PI TGC SHC PI TGC SHC PI TGC SHC PI TGC SHC PI TGC SHC PI TGC SHC PI TGC SHC PI TGC SHC PI
3200
23.9 23.9 28.0 22.9 12.73 29.5 16.7 12.97 30.8 7.1 13.12 26.5 21.7 12.92 28.0 15.8 13.18 29.2 6.7 13.43 26.2 21.4 14.72 27.4 15.5 15.08 28.5 6.6
26.7 26.7 28.5 25.9 12.76 30.1 19.5 13.00 31.4 13.6 13.15 27.0 24.6 12.95 28.5 18.5 13.21 29.7 12.8 13.46 26.7 24.3 14.76 28.0 18.1 15.12 29.1 12.5
29.4 29.4 29.1 28.0 12.79 30.7 25.2 13.03 32.1 19.1 13.18 27.6 26.5 12.98 29.1 23.9 13.24 30.3 18.1 13.49 27.2 26.2 14.80 28.5 23.4 15.16 29.7 17.7
32.2 32.2 29.7 29.1 12.82 31.4 28.5 13.07 32.7 24.1 13.22 28.1 27.6 13.01 29.7 27.0 13.28 30.9 22.8 13.53 27.8 27.2 14.83 29.1 26.5 15.20 30.3 22.3
3500
23.9 23.9 28.6 24.0 12.93 30.2 17.4 13.17 31.4 7.4 13.32 27.1 22.8 13.12 28.6 16.5 13.38 29.8 7.0 13.63 26.8 22.5 14.92 28.0 16.2 15.28 29.1 6.9
26.7 26.7 29.2 27.0 12.96 30.8 21.8 13.20 32.1 14.1 13.35 27.7 25.6 13.15 29.2 20.7 13.41 30.4 13.3 13.66 27.3 25.3 14.96 28.6 20.3 15.32 29.7 13.0
29.4 29.4 29.7 29.2 12.99 31.4 26.4 13.23 32.7 19.9 13.38 28.2 27.7 13.18 29.7 25.0 13.44 31.0 18.9 13.69 27.9 27.3 15.00 29.2 24.5 15.36 30.3 18.5
32.2 32.2 30.3 30.3 13.02 32.0 29.6 13.27 33.4 24.9 13.42 28.8 28.8 13.22 30.3 28.1 13.48 31.6 23.6 13.73 28.4 28.4 15.03 29.8 27.6 15.40 30.9 23.1
3750
23.9 23.9 29.1 26.7 12.63 30.6 19.2 13.02 31.9 8.3 13.02 27.6 25.3 13.36 29.1 18.2 13.62 30.3 7.8 13.87 27.3 25.0 15.16 28.5 17.8 15.52 29.6 7.7
26.7 26.7 29.7 29.7 12.66 31.3 24.0 12.90 32.6 15.6 13.05 28.2 28.2 13.39 29.7 22.8 13.65 30.9 14.8 13.90 27.8 27.8 15.20 29.1 22.4 15.56 30.2 14.5
29.4 29.4 30.3 30.3 12.69 31.9 29.3 12.93 33.2 22.0 13.08 28.7 28.7 13.42 30.3 27.8 13.68 31.5 20.8 13.93 28.4 28.4 15.24 29.7 27.2 15.60 30.8 20.4
32.2 32.2 30.9 30.9 12.72 32.5 29.6 12.96 33.9 27.5 13.12 29.3 29.3 13.46 30.9 28.1 13.72 32.1 26.1 13.97 28.9 28.9 15.28 30.3 27.5 15.64 31.4 25.6
4000
23.9 23.9 29.6 26.2 13.48 31.1 18.6 13.72 32.4 7.9 13.87 28.1 24.9 13.67 29.6 17.7 13.93 30.7 7.5 14.17 27.8 24.6 15.47 29.0 17.4 15.83 30.1 7.4
26.7 26.7 30.2 29.0 13.51 31.8 23.4 13.75 33.1 15.0 13.90 28.7 27.6 13.70 30.2 22.2 13.96 31.4 14.3 14.21 28.3 27.2 15.51 29.6 21.8 15.87 30.7 14.0
29.4 29.4 30.8 30.8 13.54 32.4 28.2 13.78 33.7 21.3 13.93 29.2 29.2 13.73 30.8 26.8 13.99 32.0 20.2 14.25 28.9 28.9 15.55 30.2 26.3 15.91 31.3 19.8
32.2 32.2 31.4 31.4 13.58 33.0 31.8 13.82 34.4 26.7 13.97 29.8 29.8 13.77 31.4 30.2 14.03 32.6 25.3 14.28 29.5 29.5 15.59 30.8 29.6 15.95 32.0 24.8
Notes:
1. DB = Dry Bulb Temperature (°C), WB = Wet Bulb Temperature (°C)
4. TGC = Total Cooling Capacity (kW)
5. SHC = Sensible Heating Capacity (kW)
6. PI = Power Input (kW)
