Air-cooled Package DM13-01.01.16en
32 Service manual
Gross Cooling Capacity (kW)
Outdoor DB(°C) 40.60 46.10 51.70
Indoor WB(°C) 16.10 19.40 22.80 16.10 19.40 22.80 16.10 19.40
22.80
CFM DB(°C) TGC SHC PI TGC SHC PI TGC SHC PI TGC SHC PI TGC SHC PI TGC SHC PI TGC SHC PI TGC SHC PI TGC SHC PI
4000
23.9 36.4 29.8 17.07 37.9 21.4 17.31 39.2 9.1 17.46 34.9 28.6 17.26 36.4 20.5 17.52 37.5 8.7 17.77 34.4 28.2 18.43 35.7 20.2 18.79 36.8 8.5 19.04
26.7 37.1 33.7 17.11 38.7 25.1 17.35 40.0 17.2 17.50 35.6 32.3 17.30 37.1 24.0 17.56 38.3 16.5 17.81 35.1 31.9 18.48 36.4 23.6 18.84 37.5 16.2 19.09
29.4 37.8 36.4 17.15 39.5 32.3 17.39 40.8 24.3 17.54 36.3 34.9 17.34 37.8 31.0 17.60 39.0 23.2 17.85 35.8 34.5 18.53 37.2 30.5 18.89 38.3 22.8 19.14
32.2 38.6 37.8 17.20 40.2 36.6 17.44 41.6 30.6 17.59 37.0 36.3 17.39 38.6 35.1 17.65 39.8 29.3 17.90 36.5 35.8 18.57 37.9 34.5 18.93 39.0 28.7 19.19
4300
23.9 37.0 31.1 17.27 38.5 22.3 17.51 39.8 9.4 17.66 35.5 29.8 17.46 37.0 21.4 17.72 38.1 9.0 17.97 35.0 29.5 18.63 36.3 21.0 18.99 37.4 8.8 19.24
26.7 37.7 34.9 17.31 39.3 27.9 17.55 40.6 17.8 17.70 36.2 33.5 17.50 37.7 26.7 17.76 38.9 17.1 18.01 35.8 33.1 18.68 37.1 26.3 19.04 38.2 16.7 19.29
29.4 38.5 37.7 17.35 40.1 33.7 17.59 41.4 25.3 17.74 36.9 36.2 17.54 38.5 32.3 17.80 39.7 24.2 18.06 36.5 35.8 18.73 37.8 31.8 19.09 38.9 23.7 19.34
32.2 39.2 39.2 17.40 40.9 37.9 17.64 42.2 31.5 17.79 37.7 37.7 17.59 39.2 36.3 17.85 40.5 30.2 18.10 37.2 37.2 18.77 38.5 35.7 19.14 39.7 29.6 19.39
4500
23.9 37.5 34.4 16.97 39.0 24.4 17.36 40.3 10.4 17.36 36.0 33.0 17.70 37.5 23.4 17.96 38.6 10.0 18.20 35.5 32.6 18.87 36.8 23.0 19.23 37.9 9.8 19.48
26.7 38.2 38.2 17.01 39.8 30.6 17.25 41.1 19.7 17.40 36.7 36.7 17.74 38.2 29.4 18.00 39.4 18.9 18.25 36.3 36.3 18.92 37.6 28.9 19.28 38.7 18.5 19.53
29.4 39.0 39.0 17.05 40.6 37.2 17.29 41.9 27.8 17.44 37.4 37.4 17.78 39.0 35.7 18.05 40.2 26.6 18.30 37.0 37.0 18.97 38.3 35.1 19.33 39.4 26.1 19.58
32.2 39.7 39.7 17.10 41.4 37.6 17.34 42.8 34.8 17.49 38.2 38.2 17.83 39.7 36.1 18.09 41.0 33.3 18.34 37.7 37.7 19.01 39.1 35.5 19.38 40.2 32.7 19.63
4800
23.9 37.9 33.6 17.82 39.5 23.7 18.05 40.8 10.0 18.20 36.5 32.3 18.00 37.9 22.7 18.26 39.1 9.6 18.51 36.0 31.9 19.18 37.3 22.3 19.54 38.4 9.4 19.79
26.7 38.7 37.2 17.86 40.3 29.6 18.10 41.6 18.9 18.25 37.2 35.8 18.05 38.7 28.5 18.31 39.9 18.1 18.56 36.8 35.3 19.23 38.1 28.0 19.59 39.2 17.8 19.84
29.4 39.5 39.5 17.90 41.1 35.7 18.15 42.4 26.9 18.30 37.9 37.9 18.10 39.5 34.3 18.36 40.7 25.8 18.61 37.5 37.5 19.28 38.8 33.7 19.64 39.9 25.3 19.89
32.2 40.3 40.3 17.95 41.9 40.3 18.19 43.3 33.6 18.34 38.7 38.7 18.14 40.3 38.7 18.40 41.5 32.2 18.65 38.2 38.2 19.33 39.6 38.1 19.69 40.7 31.6 19.94
Notes:
1. DB = Dry Bulb Temperature (°C), WB = Wet Bulb Temperature (°C)
4. TGC = Total Cooling Capacity (kW)
5. SHC = Sensible Heating Capacity (kW)
6. PI = Power Input (kW)
