4
ASSEMBLY INSTRUCTIONS
WARNING: IN ORDER TO AVOID OVERHEATING,
DO NOT COVER THE HEATER.
PART FIGURE
Handle
Caster assembly
Fin
[Installation of the caster assembly]
1.Place the heater body inversely with the
bottom upward.
2.Connect and tighten two wheel carrier
plates to the body with butterfly nuts as
shown in the figure.
3.Place the heater upward after it is
installed securely with the wheels touching
the ground.
7 fins heater caster assembling 9\11\13 fins heater caster assembling
