6
1-2. Loosen the screw of the left bottom angle just
as the picture shown.
3.
Use the screw to fix the bracket on the left bottom
angle of the water dispenser.
4.
Make a hole on the floor’s or the desk’s surface where
the water dispenser will be installed.
5.
Fix the bracket on the floor by screw tightly.
WARNING! To avoid a hazard due to instability of the appliance, it must be fixed in
accordance with the instructions.
Water dispenser
Bracket
The hole for
tighten screw
