Miele CVA 7440 Installation Manual

11201431-00
Installation
*INSTALLATION*
Now screw the coffee machine into the
furniture unit.
 Open the appliance door.
2 TX20 screws (25mm) are supplied.
 Secure the coffee machine to the side
walls of the housing unit using the
screws supplied. Tighten the screws
by hand.
Useful tip: You can remove the door
opening limiters and increase the door
opening angle to 170° so that the screw
on the left can be screwed in more
easily. (see "Door opening limiters").
Check whether there is enough room
and that the appliance door does not hit
an adjacent wall.
 Check the operation of the coffee
machine.
Door opening limiters
The door hinges of the coffee machine
are equipped with door opening limiters
that limit the opening angle of the
appliance door to approx. 120°. These
prevent the appliance door from hitting
an adjacent wall when opened and
being damaged.
You can remove the door opening
limiters to increase the opening angle to
approx. 170°. This allows the bean
containers to be removed more easily,
for example.
Removing the door opening limiters
Check whether there is enough room
and that the appliance door does not
hit an adjacent wall when the door
opening angle is increased.
 Remove the door opening limiters
from the hinges by levering them out
with a screwdriver, for example.
The door opening angle is now
increased to approx. 170°.

Miele CVA 7440 Specifications

General

Product type	-
Built-in grinder	Yes
Capacity in cups	1 cups
Milk adding type	Automatic
Coffee input type	Coffee beans
Coffee maker type	Fully-auto
Milk tank capacity	0.7 L
Appliance placement	Built-in
Water tank capacity	2.7 L
Coffee beans capacity	300 g
Reservoir for brewed coffee	Cup
Cord length	2 m
Control type	Touch
Product color	White
Used capsules container capacity	17 pc(s)
Current	10 A
AC input voltage	220–240 V

Weight and Dimensions

Depth	475 mm
Width	595 mm
Height	455 mm
Installation compartment depth	500 mm
Installation compartment width	560 mm
Installation compartment height	448 mm
