Miele CVA4062 - Page 44

^
Remove the cover with the milk
pipework. Clean the whole part in the
dishwasher without taking it apart.
If there are milk residues in the milk
pipework you can clean them with the
cleaning brush provided. To do this,
take the cover and the milk pipework
apart as follows:
Do not pull the milk hoses off the
retainers. This may cause the milk
pipework to leak.
^
Press the small recess on the
dispenser retainer a and pull the
retainer out towards the front b. Take
the milk hoses off the guide rail.
^
Grasp the second retainer by the
stud c and pull it up and off.
Now you can clean the hoses with the
brush under running water.
^
Insert the brush into the milk hoses
one after the other from below. Push
the brush back and forth to the end
until there is no more no milk residue
in the hoses.
Reassemble the milk pipework as
follows:
^
Push the retainer with the plug onto
the cover as shown. Make sure that
the retainer is sitting properly on the
cover.
Cleaning and care
44
