Installation
25
a
1 collar for exhaust ducting 150
mm.
b
1 reducing collar for exhaust
ducting 125 mm.
c
Conversion kit for recirculation
mode (the conversion kit is not
supplied. It must be ordered
separately as an optional accessory
- see "Technical data"). The kit
contains an exhaust grille and
flexible aluminium hose with hose
clips.
3.5x16mm screws for securing the
cooker hood.
DA 2450, 2550: 4 screws
DA 2570, 2580: 6 screws
DA 2510: 8 screws
The screws supplied are intended for
securing the cooker hood to a solid
wooden cabinet floor with a
minimum thickness of 16mm.
Ensure the floor can permanently
support the weight of the appliance.
Keep the following in a safe place:
