Installation
35
a
1 collar for e
xhaust ducting 150
mm.
b
1 reducing collar for exhaust
ducting 125 mm.
c
1 non-return flap for fittin
g into the
exhaust socket on the motor unit
(not needed for recirculation mode)
d
1 cover to close off the upper
exhaust socket when ducting to the
rear or the side (...EXT models only)
e
2 covers for installation in the
e
xtraction area
f
Conversion kit for recirculation
mode (the conversion kit is not
supplied. It
must be ordered
separately as an optional accessory
- see "Technical data"). The kit
contains an exhaust grille and
flexible aluminium hose with hose
clips.
4 x M5 x 40 mm screws, 4 washers,
4 x M5 nuts for securing
the cooker
hood to an interim shelf.
