Venting direction towards the rear:
In this case, the DAG 500 blower box
must be modified.
^
Loosen the two screws holding the
blower in the box.
^ Take the blower out of the box.
^
Remove the small cover on the rear
of the ventilation system.
^ Mount the blower on the front of the
ventilation system housing using the
2 screws while positioning the vent
collar in the opening of the cover.
Installation
29
