Miele F1411SF Dimensions

NOTE: Drawing is not to scale.
SPECIFICATION SHEETS 011208
Product and Cut-out Dimensions
72" Side by Side Combination
K1911SF & F1901SF
72"
24" min.
84"
35 3/4"
3 1/2" - 5 3/8"
35 3/4"
83 1/2" - 85 3/8"
9 1/2"
23 1/2"
1 1/4"
Notes
• See individual unit specs for location information
• KTF1072 Upper frame is required when combining to 72"
• KSK1002 Merging kit must be used when combining units
• All Installations must be done in accordance with local codes

Miele F1411SF Specifications

General

Brand	Miele
Model	F1411SF
Category	Freezer
Language	English
