Water connection spring
adapter
Make sure that the spring adapter for
water connection engages correctly
when a basket or injector unit is
inserted in the machine. It must be 4-5
mm higher than the water connection
inlet in the machine.
If it is not, adjust the adapter
accordingly.
^
Loosen lock ring a.
^
Push up adaptor b.
^
Tighten lock ring c.
Height adjustable top basket
The top basket can be adjusted above
and below the middle position by 2 cm.
Different height items can be
processed in this machine depending
on the position the top basket is set at
and the inserts used.
To adjust the top basket:
^
Pull out the top basket until a
resistance is felt; lift from the runners
and remove.
^ Unscrew the roller bearings on both
sides of the basket with a 7mm
spanner and reposition as required.
Areas of application
21
