Technical Information
52
KF 18xx/19xx
Figure 030-41: Reed Switch Removal
Figure 030-42: Reed Switch Module
4.20 Removing the Freezer Evaporator Cover
1. Disconnect the appliance from the power supply.
2. Unclip all holders (Figure 030-43, Item 1) and push to the side to remove
(Figure 030-43, Items A and B).
3. Remove all retainers (Figure 030-43, Item 2).
1 Reed switch
2 Relay
