Miele TWC220WP User Manual

11946850-00
Installation
*INSTALLATION*
 Turn the door lock through 180°.
 Press the door lock into openings 
on the opposite side of the door
opening.
 Adjust the position of the door lock
so that the screw holes line up with
those in the front panel of the dryer
.
 Secure the door lock with the two
Torx screws.
3. Remove the lock catch from the
door
 First take the rubber seal off the door
and place this to one side.
 Use a T20 Torx screwdriver to remove
screw  on the lock catch.
 Pull off the lock catch together with
lock catch cover .
 Remove the lock catch from the
cover.
This lock catch cover is no longer
needed, however, please keep it in a
safe place.

Miele TWC220WP Specifications

General

Door hinge	Left
Door style	Opaque door
Cord length	2 m
Control type	Rotary
Loading type	Front-load
Drying system	Heat pump
Product color	White
Built-in display	Yes
Reversible doors	No
Appliance placement	Freestanding
Delay start (max)	24 h
Current	10 A
Heat source	Electric
AC input voltage	220 - 240 V
AC input frequency	50 Hz
Energy consumption	1.55 kWh
Energy efficiency scale	A+++ to D
Annual energy consumption	192 kWh
Cycle time	165 min
Noise level	66 dB
Drying class	A
Drum capacity	8 kg
Refrigerating medium	R290
Number of drying programs	12
Refrigerating medium weight	110 g

Weight and Dimensions

Depth	655 mm
Width	596 mm
Height	850 mm
Weight	52000 g
Depth with door open	1077 mm
