Installation
*INSTALLATION*
Direct connection to a sink drain outlet
Use the hose holder, the adapter, the
hose clips and the non-return valve
(available to purchase).
1. Adapter
2. Nut
3. Hose clip
4. End of the hose (secured with the
hose holder)
5. Non-return valve
6. Tumble dryer drain hose
 Fit adapter 1 to the sink drain outlet
using nut 2.
The nut is usually fitted with a washer
which must be removed.
 Attach the end of the hose 4 to ad-
apter 1.
 Use the hose holder.
 Use a screwdriver to tighten hose clip
3 up close to the nut.
 Fit non-return valve 5 to tumble dryer
drain hose 6.
Non-return valve 5 has to be fitted so
that the arrow points in the direction
of flow (i.e. towards the sink).
 Secure the non-return valve using
hose clips.

Miele TWC220WP Specifications

General

Door hinge	Left
Door style	Opaque door
Cord length	2 m
Control type	Rotary
Loading type	Front-load
Drying system	Heat pump
Product color	White
Built-in display	Yes
Reversible doors	No
Appliance placement	Freestanding
Delay start (max)	24 h
Current	10 A
Heat source	Electric
AC input voltage	220 - 240 V
AC input frequency	50 Hz
Energy consumption	1.55 kWh
Energy efficiency scale	A+++ to D
Annual energy consumption	192 kWh
Cycle time	165 min
Noise level	66 dB
Drying class	A
Drum capacity	8 kg
Refrigerating medium	R290
Number of drying programs	12
Refrigerating medium weight	110 g

Weight and Dimensions

Depth	655 mm
Width	596 mm
Height	850 mm
Weight	52000 g
Depth with door open	1077 mm
