Parts List – High Discharge Accessory
Note:
Part numbers listed are available through MacKissic Inc.
Ref# Part# Description
01 930-2120-GR Deflector Weldment
02 090-0066 Bolt, HCS, 5/16-18 x 3/4
03 090-0233 Washer, Flat, 5/16
04 090-0460 Nut, Nylon Lock, 5/16-18
05 930-2119-GR High Discharge Weldment
06 708-3211 Pin, Locking
07 090-0060 Bolt, HCS, 1/4-20 X 1, Gr5
08 930-2064-GR Swivel Top, Pin Side
09 930-2063-GR Spacer, Swivel
10 940-2077-GR Flange, Side, HD
Ref# Part# Description
11 090-0470 Nut, Nylon Lock, 1/4-20
12 706-0924 Hitch Clip
13 940-2078-GR Plate, Bottom
14 930-2118-GR Swivel Weldment
15 930-2065-GR Swivel Top
Not Shown
930-0010 Label, Warning, High Speed Discharge
930-0011 Label, Danger, Rotating Knife & Flywheel
