Frame Size
Options include 8M(3840×2160), 6M(3072×2048), 5M(2592*1944),
5M(2560*1920), 5M(2560*1440), 4M(2592*1520), 3M(2304*1296),
3M(2048*1536), 1080P(1920*1080), 2M(1600 *1200), 1.3M(1280*960),
720P(1280*720), D1(704*576).
For Secondary Stream, it includes 704*576, 640*480, 640*360, 352*288,
320*240, 320*192, 320*176.
For Tertiary Stream, it include 1920*1080, 1280*720, 704*576, 640*480,
640*360, 352*288, 320*240, 320*192, 320*176.
Maximum Frame Rate
Maximum refresh frame rate of per second
Bit Rate
Transmitting bits of data per second, this item is optional only if you select the
H.265/H.264
Smart Stream
Smart Stream mode remarkably reduces the bandwidth and the data storage
requirements for network cameras while ensuring the high quality of images, and
it is a 10-level adjustable codec.
It is optional to turn On/Off Smart Stream mode.
Level: Level 1~10 are available to meet your need.
Bit Rate Control
CBR: Constant Bitrate. The rate of CBR output is constant
VBR: Variable Bitrate. VBR files vary the amount of output date per time
segment
Image Quality
Low/Medium/High are available, this item is optional only if you select VBR.
Profile
The option is for H.264, Main/High/Base can be selected according to your needs.
I-frame Interval
Set the I-frame interval to 1~120, 50 for the default. This item is optional only if
you select the H.265/H.264. The number must be a multiple of the number of
frames.
JPEG Quality
Low/Medium/High/Higher are available,
this item is optional only if you
selected the MJPEG
Note:
1) The options of [Frame Size] are variable according to the model selected.
