69
Other Alarm
Table 4-5-4 Description of the buttons
Parameters
Function Introduction
Alarm Type
Network Lost, Tampering and IP Address Conflicted are available
Check the checkbox to enable the alarm type you selected
Alarm Action
Save Into SD Card: Save alarm recording files into SD Card
External Output: If the camera equips with External Output, you can enable the
action after configuring the trigger duration
Play Audio: If the camera equips with Speaker, you can enable the action after
configuring the audio speaker
Play Buzzer: If the camera equips with Buzzer, you can check the checkbox to
enable the function
