NSEQ-4 Specifications
“Q” Range
Q = 0.4 to 4.0 Adjustable on middle ranges
Q = 1.0 Fixed on low & high ranges
Maximum Output Level
> + 28 dBu
Maximum Input Level (EQ Flat)
+ 28 dBu
Maximum Input Level (EQ Full Boost)
+ 17 dBu
Frequency Response
+0 / -3 dB
sub 2 Hz to beyond 300 kHz
Noise (All EQ Stages In, Controls Flat)
-106 dBu
Maximum Boost (21 Step Detented)
+20 dB (+10 dB with range switch in)
Maximum Cut (21 Step Detented)
-20 dB (-10 dB with range switch in)
EQ Frequencies
Low Range Switch (Centers - Peak/Shelf Selectable):
20, 34, 56, 100, 180, 270
Low Mid Sweep:
20 Hz - 220 Hz or 200 Hz - 2.2 kHz.
10X Range switch selectable.
Hi Mid Sweep:
250 Hz - 2.5 kHz or 2.5 kHz - 25 kHz.
10X Range switch selectable.
High Range Switch (Centers - Peak/Shelf Selectable)
4.8 k, 5.8 k, 8.0 k, 10 k, 16 k, 21 k
THD + Noise
20 Hz - 30 kHz, All EQ Bands Switched In
< .009%, typ < .003 %
Common Mode Rejection Ratio
10 Hz - 20 KHz, 100 mV C.M.
> 60 dB, Typ > 80 dB
Slew Rate, +27 dBu Out
> 50 volts per microsecond
Main Hard-wire Bypass Switch For Each Channel?
Yes
Peak/Shelf Selection On High & Low Range?
Yes
Hard-wire Bypass Switching On Individual EQ Bands?
Yes
Input Impedance
25 kilohms
Minimum Output Load Impedance
50 ohms
Recommended Load
> 500 ohms
Output Impedance
5 ohms
EQ Amplifiers
Pure Class-A Discrete J-FETs
Power Consumption
30 watts maximum
Power Requirements
Selectable: 100-120, 200-240 V ac, 50/60 Hz
Dimensions/Shipping Weight
19” W x 3.5” H x 12.5”, 25 lbs.
