OM-2228 Page 33
206 305-A
206305-A
Turnoffpowerbefore
checkingtorchparts.
Checkbeforeeach
useandhourly
duringoperation.
CAUTION
FAILURETORE-
PLACEWORNTIP
ORELECTRODE
WILLRUINTORCH
ANDVOID
WARRANTY.
ICE-55C
CONSUMABLES
Standard
DragShield
192053
Shield
192058
Deflector
177888
RetainingCup
192050
RetainingCup
192050
40ATip
192052
Electrode
192048
RetainingCup
192050
Tip
192204
Tip
192051
Electrode
192047
Electrode
192047
SwirlRing
192049
O-Ring
169232
Machine
Extended
Cutting
Cutting
Cutting
1/8”(3mm)
stand-off
recommended
Shield
192203
Applysilicone
grease(169231)
beforeinstalling.
Gouging
55ATip
192056
Figure 8-3. Consumable Parts For ICE-55C And 55CM
1 192 050 Cup, shield (1)
2 169 232 O-Ring, 55A (1)
3 192 060 Main Body (1)
4 180 610 Position Sleeve (1)
5 192 061 Leads, 50ft (1)
6 180 605 Remote Pendent Control (1)
7 198 643 Torch Sleeve (1)
8 192 058 Shield, machine (1)
9 198 644 Ring, retaining (1)
169 231 Grease, silicone (1)
193 349 Torch, replacement 50ft (1)
Part
No.
Item
No. Description
5
3
4
6
7
2
1
9
8
See 8-3 for
additional consumable parts.
Figure 8-4. Torch, ICE-55CM
