In Case of Trouble
Status message
The messages given below appear in the remote mode.
They do not indicate errors but require an appropriate action.
Message Cause Remedy
** OFFSCALE **
The cutting data exceeds the effective
cutting area.
Or the plotter has stopped after cutting the
sheet up to its end normally.
Use a larger sheet, decrease the amount of
data or execute the divided cutting function.
** NO SHEET **
No sheet has been set or a transparent
sheet has been set.
Load a sheet or turn off the sheet sensor.
** VIEW **
The plotter has received the not-ready-
mode (NR;) signal from the host computer
and has entered the local mode.
Execute the required operations, such as
the sheet detection or the establishment of
an origin. Then, press the key to
make the plotter to enter the remote mode.
** DIGITIZE **
The plotter has received the digitization
command (DP;) from the host computer
and has entered the digitization mode.
Move the pen to a desired location, where
necessary, and press the key.
To reset the digitization mode, execute the
data clear using the key.
** END COPY **
The plotter has terminated copying after
completion of one sheet copying, since the
data received contains the origin updating
command (ZT;, !PG;).
The plural sheets cutting function is
disabled. To perform plural sheets cutting,
change the setting back to enable the
function on the host computer.
* DIVISION * 5s
The plotter has finished the cutting
corresponding to a division of the data that
exceeds the sheet width, using the division
cut function, and is now waiting for the
receipt of the next data.
If the plotter does not receive any data from
the host computer within ten seconds, it will
recognize the data has ended.
Then, the plotter will perform the frame
cutting and mark cutting and enter the local
mode.
* END DIVISION *
This message appears in any of the
following cases:
The plotter has received data that contains
the origin updating command (ZT;, !PG;).
The sheet width is 1 cm or less.
The sample cutting data exceeds the sheet
width.
The two-point axis alignment is set to ON.
Registration marks have already detected.
Division cut is disabled.
