Clamp pressure lever
This lever adjusts the force by
which the clamp is held.
(P.1-8)
Tray
Small tools, such as a retractable knife and
other cutters, can be placed on.
Roll bar
A roll sheet is placed on the two roll
bars. ( P.2-19)
AC inlet
The power cable is
connected to the AC
inlet.( P.1-10)
Sheet sensor
This sensor detects the presence of
the sheet and sheet length. ( P.1-
8)
Roll stay
Roll stays support the roll
bars.
( P.2-19)
RS-232C interface connector
The RS-232C interface
connector. ( P.1-9)
LAN connector
The LAN connector.
Please use when you use
event mail function.
USB interface connector
The USB interface connector.
(P.1-9)
