MIMAKI CG-60SRIII - Set the X Direction (Feeding Direction) DIVISION Cut

3-41
1
1
3
Useful Function
5
6
Perform DIVISION cut
Set the X direction (feeding direction) DIVISION cut
If the data size of the feeding direction exceeds the
division length and cross cut length, the machine cuts it
at that position by dividing it.
If the cross cut length is set, the machine cuts by
overlapping it by the set value.
1
Press the key in the local mode.
2
Press the jog key or to select [SET UP] .
3
Press the key.
4
Press the jog key or to select [DIVISION
cut].
5
Press the key.
6
Press the jog key or to select “X”.
7
Press the key.
Cross Cut Length
Division Length
FUNCTION
ENTER/HOLD
ENTER/HOLD
ENTER/HOLD
