Chapter 2 Cutting
63
3
Fix the lock nut by turning in the direction indicated by the arrow in the picture.
Adjusting the Cutting Blade Protrusion Length
1
Loosen the lock nut of the cutter holder.
2
Turn the adjusting knob to adjust the protrusion of the cutting blade.
3
Fix the lock nut by turning in the direction indicated by the arrow in the picture.
Using a Pen
Installing a Refill Cartridge for a Ballpoint Pen in the Pen Holder (Standard)
The image quality can vary depending on the type of refill cartridge.
Recommended: SXR-5 (Mitsubishi Pencil Co., Ltd.)
2
To Next Page
