Mimosa CAYMEN User Manual

Note:
1 Please carefully read all instructions before assembly and use
2.PIease separate and identify all parts, ensuring that you have all parts listed
3.To avoid damaging your umbrella, it is recommended that you assemble it on a
clean, protected surface
4.Washers must be used when indicated during the assembly process
5.Loosely tighten the nuts and then securely tighten when all are in position. Be careful
not to over tighten the nuts during assembly.
IMPORTANT: Please read these instructions before using the product and retain
for future use.
Parts List
Part No. Description Quantity
Pictures
Part No. Description Quantity
Pictures
A
B
C
D
E
Frame &
canopy
Upper
Beam
Upright
pole
Cross
base
Cross
base
L-Shape
base
Base support
Connecting
elbow
Square tube
hook
Crank box
Protection box
F
G
H
I
J
K
1
1
1
1
1
4
1
1
1
1
1
WARNING:
Not for children under 3 yrs.
CAUTION! Functional sharp points and edges. Use with care.
To be used under the direct supervision of an adult.
Hardware List
aa
bb
cc
Bolt & nut
(M I0*120mm)
Spanner
Crank Handle4 set
2
1
Include bolts and nuts
Include bolts and nuts
Include bolts and nuts
