16
Internal wiring diagram of SB−310
YERD WH BLGR
to CSD−891B
Suitable crimp type
terminal lugs：
A：3.2 mm or less
B：7 mm or less
Short bar
Output port
Input port
No.4
・Y type ・Round type
or
B
A
φA
φB
Input port No.3
Input port No.2
Input port No.1
YERD WH BLGR
YERD WH BLGR
YERD WH BLGR
YE
RD
WH
BL
GR
ii) When CAB−501(6−cores cable) is used.
CAB−501
SB−310
Black
Orange
White
Blue ※1
Shield
Green ※1
Red
Junction box
※2 (The length of CAB−501 is within 100 m totally.)
