56
Procedures
6
Transmit the command for “Status reading out
during the calibration” from the host. According
to the return data, proceed to the following steps.
・The return data is “END”
As termination is in normal, proceed to the
next step.
・The return data is “TE−L”
The initial load is less than −2.5 mV/V.
Set the initial load within the range from −2.5
mV/V to 2.5 mV/V, and proceed to step 5.
・The return data is “TE−H”.
The initial load is exceeding over 2.5 mV/V.
Set the initial load within the range from −2.5
mV/V to 2.5 mV/V, and proceed to the step 5.
・The return data is “ZERO”
Now under the calibration.
Until the return data becomes except “ZERO”,
repeat to transmit the command for “Status
reading out during the calibration” from the
host.
The display in the load display section displays
“−RS−” and “END” alternately.
2 4 6 8 10 12 14
@ 0 0 0 9 E N D Termi
ID No.
Command CSD−891B→Host
・Normal termination
2 4 6 8 10 12 14
@ 0 0 0 9 T E - L Termi
ID No.
2 4 6 8 10 12 14
@ 0 0 0 9 T E - H Termi
ID No.
2 4 6 8 10 12 14
@ 0 0 0 9 Z E R O Termi
ID No.
246
@ 0 0 0 9 Terminator
Command Host→CSD−891B
ID No.
・Low input
・High input
・During the calibration
-nator
-nator
-nator
-nator
7
Transmit the termination command of the
calibration from the host.
The calibration data is made effective and the
calibration mode is over.
The display in the load display section displays
the present load value.
246
@ 0 0 1 9 Terminator
Command Host→CSD−891B
R
eturn
C
SD 891B
→
Host
ID No.
7
2 4 6 8 10 12 14
@ 0 0 1 9 E N D Termi
R
eturn
C
SD
−
891B
→
H
ost
・Normal termination
ID No.
-nator
