Parameter List:
NAME DESCRIPTION
OPENUPSMODE OPENUPS mode
0- Auto restart when Input Power is
Present=YES
1- Auto restart when Input Power is
Present=NO
UPS_CONFIG Configuration register. Used for enabling
disabling modules. LSB bit is b0.
b6- Stop impulse
b5- Start impulse
b4- Coulomb counter
b3- A/D Low pass Filter module
b2- Balance module
b1- Charge module
b0- Output module
Default is all enabled
UPS_INIT_DELAY_TOUT[s] Initial delay before starting the UPS.
Default is 1 sec.
UPS_VIN_MAX_SHUTDOWN[V] Max allowed input voltage. In case input
voltage exceeds predefined value
shutdown will be initiated.
Default is 35V.
UPS_VIN_MIN_START [V] If input voltage is above this threshold the
UPS will start and take power from the
input.
Default is 11V.
UPS_VIN_MIN_STOP [V] If input voltage is below this threshold the
UPS will try to run on battery.
Default is 6V.
UPS_VCELL_MIN_START [V] If Vin is not present and all the battery
cells are above this threshold the UPS
can start and runs on battery
Default is 11.7V
UPS_VCELL_MIN_STOP [V] If VIN is not present and one of the
battery cells is less than this threshold
during the time period specified by
UPS_VBAT_UVP_OFF_TOUT parameter
the UPS will initiate shut down procedure.
Default is 11.4V
UPS_VBAT_UVP_OFF_TOUT [s] During this period battery cells are
checked against
UPS_VCELL_MIN_STOP. If cell voltage
exceeds UPS_VCELL_MIN_STOP the
timer is rearmed so it can filter unwanted
noise in the system.
