In addition, the tail lights in the bumper as-
sume the functions of the brake light, tail
light and turn signals, if the split doors are
open.
Overview
1 Tail lights/brake lights/turn signal
2 Brake lights/turn signals
Tail lights/brake lights/turn signal
21-watt bulbs, P21W.
1. Press out cover below the tail light.
2. Remove the screwdriver from the on-
board vehicle tool kit.
3. Pull the screwdriver blade from the han-
dle and place it on the recessed-head
screw head in the bumper.
4. Attach the screw driver handle with the
slot to the blade, arrow 1.
5. Loosen screw in the bumper, arrow 2.
6. Pull tail light from the bumper.
Seite 297
Replacing components MOBILITY
297
