– Depending on the vehicle equipment,
get wheel change tools and, if necessary,
the emergency wheel from the vehicle.
– If necessary, set up a warning triangle
or portable hazard warning light at an
appropriate distance.
– Secure the vehicle additionally against
rolling.
– Loosen the lug bolts a half turn.
Jacking points for the vehicle jack
The jacking points for the vehicle jack are
located at the marked positions.
Jacking up the vehicle
Warning
Hands and fingers can be jammed when
using the vehicle jack. There is a risk of
injury. Comply with the described hand
position and do not change this position
while using the vehicle jack.
1. Hold the vehicle jack with one hand, ar-
row 1, and grasp the vehicle jack crank
or lever with your other hand, arrow 2.
2. Insert the vehicle jack into the rectan-
gular recess of the jacking point closest
to the wheel to be changed.
Seite 277
Wheels and tires MOBILITY
277
Online Edition for Part no. 01402666575 - VI/19
