35
area above the controls cover (7) is a 2” LCD display (6)
and the two status LEDs for the operating status and the
battery charge level (5,6). The two battery compartments
(16) are located on both sides of the camera housing and
are fitted with screw cap closings.
To close the camera housing, proceed as follows:
1. Hold your DTC 400 in one hand.
2. Hold the latch (10) between two fingers and flip the
controls cover (7) shut to the right side.
3. Apply light pressure until it clicks into place.
4. Then flip the locking latch (9) forwards and insert the
latch (10) through the hole provided.
5. Turn the latch (10) by 90° so that the recess for the lock
can be seen when you look at the camera head-on.
Inserting the batteries
Your DTC 400 camera is designed for alkaline, lithium or
nickel-metal hydride (NiMH) AA batteries. To insert the
batteries, unscrew the two battery compartments (16)
counter clockwise. Insert 4 x 1.5 volt AA batteries into
each of the two battery compartments (16) as instructed.
Pay attention to the correct insertion direction/polarity
(+/-). Close the two battery compartments (16) again by
tightening the screw caps in a clockwise direction.
Note: Your DTC 400 Wildlife Camera is a high precision
device of premium technical quality. It is recommended
that you use premium quality alkaline, lithium or NiMH
batteries.
