Minox MD 7x42 C Instructions

16
Focussing
To focus on a subject with a high level of pre-
cision, it is important to set the lens of the
monocular using the following steps:
(a) Position the eyepiece of the monocular in
front of one eye and look through it. Please
close the other eye.
(b) Get your subject in sight.
(c) Now turn the focussing ring (2) to the left
or the right until the subject is sharp.
You are now using your MINOX monocular
as it should be used. Of course, if you or your
subject moves, just re-focus.
2
6
Note: Make sure, that you do not cover the
light well with your fingers.

Minox MD 7x42 C Specifications

General

Exit pupil	6 mm
Eye relief	18 mm
Prism type	Roof
Field of view	113.4 - 1000 m
Magnification	7 x
Twilight factor	17.2
Objective diameter	42 mm
Apparent field of view	6.5 °
Operating temperature (T-T)	-20 - 50 °C
Waterproof	Yes
Waterproof up to	5 m

Weight and Dimensions

Depth	143 mm
Width	61 mm
Height	65 mm
Weight	370 g
