Minox MD 7x42 C User Manual

26
Focussing
To focus on a subject with a high level of precision, it is important
to set the lens of the monocular using the following steps:
a) Position the eyepiece of the monocular in front of one eye and
look through it. Please close the other eye.
b) Get your subject in sight.
c) Now turn the focussing ring (2) to the left or the right until
the subject is sharp.
You are now using your MINOX monocular as it should be used. Of
course, if you or your subject moves, just re-focus.
6
2
Note: Make sure, that you do not cover the light well with
your fingers.

Minox MD 7x42 C Specifications

General

Exit pupil	6 mm
Eye relief	18 mm
Prism type	Roof
Field of view	113.4 - 1000 m
Magnification	7 x
Twilight factor	17.2
Objective diameter	42 mm
Apparent field of view	6.5 °
Operating temperature (T-T)	-20 - 50 °C
Waterproof	Yes
Waterproof up to	5 m

Weight and Dimensions

Depth	143 mm
Width	61 mm
Height	65 mm
Weight	370 g
