Minox MD 7x42 C User Manual

31
How to Work the Compass
When using a compass, the direction is read in degrees. As the
Figure 4 showed, north would be an azimuth of 360°, east would
be an azimuth of 90°, south would be an azimuth of 180°and west
would be an azimuth of 270°.
10
10
10
20
30
10 20
20
20 30
30
30 40
40
40 50
50
50
180
190
170
180
190
170
Viewing direction: The South (180°)
Note: One graduation represents 1 degree.

Minox MD 7x42 C Specifications

General

Exit pupil	6 mm
Eye relief	18 mm
Prism type	Roof
Field of view	113.4 - 1000 m
Magnification	7 x
Twilight factor	17.2
Objective diameter	42 mm
Apparent field of view	6.5 °
Operating temperature (T-T)	-20 - 50 °C
Waterproof	Yes
Waterproof up to	5 m

Weight and Dimensions

Depth	143 mm
Width	61 mm
Height	65 mm
Weight	370 g
