Minox MD 7x42 C User Manual

38
Declaration of conformity
The manufacturer hereby declares that this CE mar-
king has been affixed to this device in accordance with
the essential requirements and other relevant provisions of the
following European Directives:
2011/65/EG RoHs Directive
2014/30/EN EMV Directive
The EC Declaration of Conformity can be obtained from the address
provided at the end of this manual.

Minox MD 7x42 C Specifications

General

Exit pupil	6 mm
Eye relief	18 mm
Prism type	Roof
Field of view	113.4 - 1000 m
Magnification	7 x
Twilight factor	17.2
Objective diameter	42 mm
Apparent field of view	6.5 °
Operating temperature (T-T)	-20 - 50 °C
Waterproof	Yes
Waterproof up to	5 m

Weight and Dimensions

Depth	143 mm
Width	61 mm
Height	65 mm
Weight	370 g
