Mipro MA-708 - Page 54

CIRCUIT
：
1PA088B2 A708P01B
PART LIST
COMPUCTOR NO. REFETENCE VALUE
1CENCA476 C1 47u/25V
1CENCA476 C2 47u/25V
1CENDA477 C3 470u/35V
1CENDA477 C4 470u/35V
1CCS6X472 C5 472P
1CCS6X102 C6 102P
1CCS6X102 C7 102P
1CCS6X102 C8 102P
1CCS6X102 C9 102P
1CCS6X102 C10 102P
1CCS6X102 C11 102P
1CENCA106 C12 10u/25V
1CENCA106 C13 10u/25V
1CENCA106 C14 10u/25V
1CENCA106 C15 10u/25V
1CENCA106 C16 10u/25V
1CENCA106 C17 10u/25V
1CENCA106 C18 10u/25V
1CENCA106 C19 10u/25V
1CCS6X104 C20 104P
1CCS8P471 C21 470P
1CCS8X104 C22 104P
1CCS8X104 C23 104P
1CCS8X104 C24 104P
1CCS8X104 C25 104P
1CENDA228 C26 2200u/35V
1CENEA225 C27 2.2U/50VE
1CENEA225 C28 2.2U/50VE
1CEMCA226 C29 22u/25V
1CEMCA226 C30 22u/25V
1CEMCA226 C31 22u/25V
1CEMCA226 C32 22u/25V
1CCS6X102 C33 102P
1CCS6X102 C35 102P
1CNNKJ684 C37 0.68u/100V
1CNNKJ684 C38 0.68u/100V
1CNNKJ474 C39 0.47u/100V
1CENDA477 C40 470u/35V
1CENDA477 C41 470u/35V
1CCS8X104 C42 104P
1CCS8X104 C43 104P
1CCS8P471 C44 470P
1CCS8X104 C45 104P
COMPUCTOR NO. REFETENCE VALUE
1DDS4148 D3 1DDS4148
1DDS4148 D4 1DDS4148
1DDS4148 D5 1DDS4148
1DDS4148 D6 1DDS4148
1DDS001D D7 1DDS001D
1DDS001D D8 1DDS001D
1DDS001D D9 1DDS001D
1DDS001D D10 1DDS001D
1LLNA126 L1 1LLNA126
1LLNA126 L2 1LLNA126
1LLNA601 L3 1LLNA601
1SFHB02A P1 1SFHB02A
1SFHB02A P2 1SFHB02A
1SFHC03B P3 1SFHC03B
1SFHC03B P4 1SFHC03B
1TNRF530 Q4 1TNRF530
1TNRF530 Q5 1TNRF530
1TNRF530 Q6 1TNRF530
1TNRF530 Q7 1TNRF530
1RNC0221 R1 220
1RNC0221 R2 220
1RS8B103 R3 10k
1RS8B103 R4 10k
1RS8B222 R5 2.2K
1RS8B005 R6 4.7
1RS8B005 R7 4.7
1RS6A203 R9 20K
1RS8B000 R10 0
1RS6A203 R11 20K
1RS6A203 R12 20k
1RS6A203 R13 20k
1RS6A203 R14 20k
1RS6A101 R15 1K
1RS6A000 R16 0
1RS6A000 R17 0
1RS8B010 R18 10
1RS8B010 R19 10
1RS6A103 R20 10k
1RS6A103 R21 10k
1RS6A103 R22 10k
