Mipro MA-708 - Page 62

CIRCUIT
：
1PA074B1 A708P01B
PART LIST
COMPUCTOR NO. REFETENCE VALUE
1CENCB477 C1 470uF/25V
1CCS8Y104 C2 104P
1CCS6P471 C3 470P
1CCS6P471 C4 470P
1CCS6X103 C5 103P
1CCS6X103 C6 103P
1CCS6X103 C7 103P
1CCS6X103 C8 103P
1CCS6X103 C9 103P
1CCS6X103 C10 103P
1CCS6P471 C11 470P
1CCS6P471 C12 470P
1CCS6P471 C13 470P
1CCS6P471 C14 470P
1CCS6X103 C10 103P
1CCS6P471 C11 470P
1CCS6P471 C12 470P
1CCS6P471 C13 470P
1CCS6P471 C14 470P
1SFHD10B EP1 1SFHD10B
1SFHD10B EP2 1SFHD10B
1SFHD10B EP3 1SFHD10B
1SFVB05A J1 1SFVB05A
1MPR0001 J2 1MPR0001
1MPR0001 J3 1MPR0001
1MPR0001 J4 1MPR0001
1MPR0001 J5 1MPR0001
1SFVB03A J6 1SFVB03A
1LCSR004 L1 1LCSR004
1LCSR004 L2 1LCSR004
1LCSR005 L3 1LCSR005
1LCSR004 L4 1LCSR004
1LCSR004 L5 1LCSR004
1LCSR005 L6 1LCSR005
1LCSR004 L7 1LCSR004
1LCSR004 L8 1LCSR004
1LCSR005 L9 1LCSR005
1LCSR004 L10 1LCSR004
1LCSR004 L11 1LCSR004
1LCSR005 L12 1LCSR005
COMPUCTOR NO. REFETENCE VALUE
1LLS8224 L13 1LLS8224
1SFVB06A P2 1SFVB06A
1RS6A101 R1 100
1RS6A101 R2 100
1RS6A101 R3 100
1RS6A101 R4 100
1RS6A000 R5 0
1RS6A010 R6 10
1RS6A103 R7 10K
1RS6A010 R8 10
1RS6A103 R9 10K
1RS6A010 R10 10
1RS6A103 R11 10K
1RS6A010 R12 10
1RS6A103 R13 10K
