INSTALLATION OF MIPRO CD/MP3 PLAYER
! Using a Phillips-head screwdriver (not supplied) remove the screws to remove protection
cover panel. (see figure 2-1)
! Gently insert the CD/MP3 player module into the slot. Make sure the back edge
connector is aligned and firmly connected. (see figure 2-2)
! Tighten up the screws. (see figure 2-3)
OPERATIONS OF CD/MP3 PLAYER
See a separate CD player manual enclosed in the master carton.
(Figure 2-1) (Figure 2-2) (Figure 2-3)
1. We recommend placing sound system between the target audience and the presenter,
facing the audience and raised above their heads using a speaker stand or table. This
set-up helps prevent the annoying feedback by keeping wireless & wired microphone
users behind the sound system. The internal power supply rechargeable, lead-acid
batteries should be kept fully charged. Always charge the system after use.
2. Minimized all the volumes before powering on.
3. Each audio input is accepted through amplifier and its volume can be controlled
separately.
4. Each audio input can be broadcasted and recorded at the same time.
5. This speaker fits into a standard speaker tripod stand. For optimal usage, operate the
wireless microphones from a distance behind or beside the speaker to avoid the
undesirable feedback.
6. Do not expose the MA-708 to an environment where there are water dropping or
splashing.
7. Before turning power ON to the unit, please set all volume controls to their minimum
level. This prevents any loud 'thumps' at power on. Adjust the volume controls afterward.
8. NEVER place any microphone in front or close in front of the speaker otherwise damaging
feedback (both to the operators ears and the system) could occur.
9. The MA-708 features a retractable handle and wheels for easy transport. However, DO
NOT pull the unit for long distances or over uneven or rough surfaces. And, DO NOT pull
it up or down stairs. Vibration caused by long distance travel or traveling over uneven
surfaces may result in function failure not covered by warranty.
10. The MA-708-EXP extension speaker is rated at 120 watts @ 4 ohms. Please take care not
to short out the speaker cables otherwise unwarranted damage could be done to the
system amplifier.
HELPFUL OPERATING TIPS
MTM-90/MTM-92 COMPARTMENT FOR BODYPACK TRANSMITTER
Compartment holds and stores one body pack transmitter.
Locate the compartment fastener on the left hand side.
Turn fastener clockwise to loose the compartment door.
Gently pull the compartment door away from the slot.
Slide the back of the bodypack transmitter into the back of the compartment door in
position, carefully keep the antenna in horizontal position to prevent from being
squeezed.
When secured, push in the compartment door back into the slot.
Turn fastener counter clockwise to secure the compartment door.
Storing the body pack transmitter:
B
E
A
D
C
F
B
E
A
D
C
F
G
14
15
PORTABLE WIRELESS PA SYSTEM PORTABLE WIRELESS PA SYSTEM
