MiraBox HSV373 - Application; Single Output Extension; Multiple Output Extension

HDMI Source
HDMI Extender
Sender
HDMI Extender
Receiver
Cat5e/6 Cable
HDMI IN HDMI OUT
Xbox One
Monitor
HDMI IN
Cat5e/6 Cable
Cat5e/6Cable
Cat5e/6 Cable
HDMI OUT
HDMI OUT
HDMI OUT
Cat5e/6 Cable
HDMI Extender
Sender
HDMI Extender
Receiver
HDMI Extender
Receiver
HDMI Extender
Receiver
HDMI Media player
Monitor
Monitor
Monitor
6. Power on your HDMI device and HDMI
display.
7. The HDMI Extender is ready for use.
Application
1. Single output: Extend HDMI signals up to
120 meters over one CAT5/5e/6 cable.
2. Multiple outputs: Extend and split using
network router/switch.
- One Extender (TX) to several Receivers(RX)
