30
FIGURE 1
Connecting speakers with
normal speaker wire.
Left Speaker
IMPORTANT NOTE!
Ensure that one gold
shorting bar is connected
as shown between the two
Red Input terminals and
the two Black Input
terminals on the back of
the speaker.
Connect the Right
Speaker exactly the
same way.
Amplifier
- +
- +
- +
- +
FIGURE 2
Connecting your speakers
in the Bi Wire fashion.
Left Speaker
DANGER!
The gold shorting bars,
which have been factory
installed between both
Red and Black
terminals MUST BE
REMOVED.
Connect the Right
Speaker exactly the
same way.
Amplifier
- + - +
2 – 3m
.5-1m
.4-1m
RIGHT REAR
LEFT REAR
LEFT MAIN
RIGHT MAIN
SUBWOOFER
CENTER
CHANNEL
FIGURE 3 FIGURE 4
