SPECIFICATIONS
MISSION 776 PRE-AMPLIFIER
Input Sensitivity:
Phono: 2mV. for 1 Volt rms output
Line: 100mV for 1 Volt rms output
Input Overload at 1 kHz: Phono stage 150m.v.
Output Level:
Nominal 1 Volt rms
Maximum 11 Volts peak
Input Impedance: 47kΩ, 150pF.
Output Impedance: 250Ω, 4µ7F.
Signal/Noise:
Phono input 80dB "A" weighted 20Hz-20kHz (ref. 5mV input)
Line input 95dB "CCIR" weighted 20Hz-20kHz (ref. 200mV input)
HUM >100dB below rated output
Volume Control: Channels track within 0.2dB from 0dB down to -70dB
Distortion:
THD: <0.5% (20Hz-20kHz)
IMD: <0.5% (60Hz & 7kHz at 4:1)
TID: immeasurable
Frequency Response:
Phono:
+0.2dB 20Hz~20kHz
-3dB 10Hz~50kHz
Line: -0.2dB 20Hz & 20kHz
